LRX-20-50W-MCTP

LED Multi-Power & Multi-CCT Area Light, 20W/30W/40W/50W, 3500K/4000K/5000K/5700K

Technical Specs

  • :: Die-cast ADC12 Aluminum Alloy, Outdoor Powder Coated
  • :: 1-1/4" EMT Elbow & Mounting Strap Included
  • :: NEMA Twist-Lock Photocell Included
  • :: Multi-CCT, Switch on bottom of fixture
  • :: Dimming: 0-10V Dimming
  • :: Lens: Polycarbonate Lens, High light transmittance PC, Anti-UV and Fire Resistant
  • :: Aluminum LED Board: High conductive, waterproof, aging resistant, salt resistant
  • :: Lumens Range: 2950-6500LM
  • :: Wattage: 20W/30W/40W/50W
  • :: Voltage: 120~277V AC 60Hz
  • :: Efficacy: 130LPW
  • :: Beam Angle: 90° x 110°
  • :: Power Factor: >0.90
  • :: Operating Temp: -4°F to 104°F
  • :: THD: <20%
  • :: Color Rendering Index: CRI ≥ 70
  • :: Color Temp: 3500K/4000K/5000K/5700K
  • :: Lifespan: 70,000 hours
  • :: 7-year warranty
  • :: IP Rating: IP44, Wet Locations

Applications

  • :: LED Dusk to dawn light with photocell ideal for general site lighting, yard/barn lighting, loading docks, doorway, pathway and parking areas.

Features

  • DLC Listed
  • UL Listed
  • Dimming 0-10V
  • Wet Location
  • 7 year warranty
  • MCTP
