IGLA-3W-30K-BN

:: Die-cast aluminum housing
:: Traffic rated: not likely to get damaged from activity around the light, including lawn care, as well as foot and auto traffic
:: Solid state lighting technology for long life, no maintenance needed and high-efficiency
:: 4" PVC sleeve with three 1/2-inch KO. 2 on sides, 1 on bottom.
:: High conductive aluminum LED board
:: LED: Built in integrated LED
:: Optical PC Flat Lens
:: Lumens: 320LM
:: Wattage: 3W
:: Voltage: 12-24V AC/DC
:: Input Current: 1A Max
:: Efficacy: 106LPW
:: Beam Angle: 30°
:: Power Factor: >0.9
:: Operating Temperature: -4°F ~ 104°F
:: Color Rendering Index: CRI ≥ 90
:: Color Temp: 3000K
:: Lifespan: 50,000 hours
:: 1-year warranty
:: IP Rating: IP67, Wet Location

:: The fixture has classic traditional appearance, professional light distribution design, ideal for park landscaping, garden, architectural landscape lighting, suitable for wet locations
