EXPF-100W-60K
Hazardous Location Flood/Highbay Lights, 100W, 6000K
Technical Specs
- :: Class I, Division 2 - UL No.: IFUX.E503444
- :: Die-cast Aluminum with powder coat finish (gray)
- :: Surge Protection: IEC/EN 61000-4-5
- :: Cord Type: 2' SJTW 18/3 AWG Cable
- :: 70%-80% Saving Compare to HPS/MH
- :: EMC Test Standard
- :: Lens: Super Clear Tempered Glass
- :: Lumens: 11500LM
- :: Wattage: 100W
- :: Voltage: 100~277VAC, 50/60Hz
- :: Efficacy: Up to 110LM/W
- :: Power Factor: 0.90 ~ 0.98
- :: Operating Temp: -22°F to 122°F
- :: Total Harmonic Distortion (THD): <10%
- :: Color Temp: 6000K
- :: Lifespan: 100,000 hours
- :: IP Rating: IP68, Suitable for Hazardous Locations
Applications
- :: Ideal for oil and gas refineries, drilling rigs, petrochemical facilities, food and beverage facilities, loading docks, tunnels, outdoor wall and general area lighting and where flammable vapors, gases, ignitable dusts, fibers or flying are often present. Where extremely corrosive, wet, dusty, hot and/or cold conditions exist.
